Hofmann Geoliner 770XD - Diagnostic Wheel Alignment System (with AC200 Clamps & Vin Reader)


Please call us for customization options.

Ideal for high-volume shops that specialize in alignments and wheel service, the Hofmann® geoliner® 770 Diagnostic Wheel Alignment System delivers sophistication in a compact footprint, designed to fit where you need it and move pretty much anywhere else. The short boot-up gets your team to every job quickly, with faster measurements for more efficient, more accurate alignments every time.

Groundbreaking User Interface

The geoliner® 770 Diagnostic Wheel Alignment System features a next-generation interface that provides instant access to critical tasks in an intelligent flow, ensuring vehicle-specific assistance is never more than just one click away.

Hofmann Geoliner 770XD User Interface
  • Optimized vehicle selection process:
    • Quick Access to history right on the home screen
    • Clear and comprehensive make/year/model selection
    • Quick model search
    • Manual and scanner VIN select, with live lookup feature
  • Quick-select language support for procedures and printouts providesrapid changes between commonly used languages
  • All new graphic displays with all screens optimized for maximum visibility and clarity

Video Speed Cameras Constantly Monitor Alignments, Providing Information at Every Step

The geoliner® 770’s advanced XD cameras and sophisticated monitoring algorithms find errors as they’re made, detecting problems with suspension stress and damage, rack, clamps, environment, and more - notifying users only when necessary to save time and ensure accuracy on every alignment.

Hofmann Geoliner 770XD Video Speed Cameras
  • Compensate: Error is completely compensated with no notification to the user
  • Warn: Error is completely compensated with user warned that a correction
    action is required
  • Alert: Critical error leading to a bad alignment is detected; user notified that corrective action is required

Automatic Height Tracking Saves Time On Every Job

Hofmann Geoliner 770XD Height Tracking

The V3300 wheel alignment system’s automatic height tracking provides optimum placement of its advanced XD targets and cameras for more speed and more accuracy
on every alignment. And since the lightweight, three-camera system folds to a compact size with a low center
of gravity, the V3300 takes up less floor space in the
shop and can be moved around easily whenever required.

* Low-profile design lowers the center of gravity from improved stability when moving.

Hofmann Geoliner 770XD AC200 Universal Wheel Clamps

AC200 Universal Wheel Clamp

  • Rugged cast aluminum construction
  • Self-centering design for accurate measurement and vehicle dimensions
  • Two sided claws, eliminate accessories and allow reliable clamping even over hubcaps
  • Accessories available to accommodate larger wheels

Hofmann Geoliner 770XD Wireless CommunicationWireless Communication
Navigate, monitor and control the unit from anywhere in the shop

Hofmann Geoliner 770XD Folding Beams

Folding Camera Beams
Improved stability during transport with camera protection built right in

Hofmann Geoliner 770XD low-profile

Lightweight, Low-Profile: Fits Easily Through Standard Doorways

The geoliner™ 770's lightweight three-camera system folds to a compact size with a low center of gravity, meaning it takes up less floor space in the shop and can be moved around easily whenever required. Integrated wireless connectivity provides a seamless connection between the aligner and the viewing device - so no matter how challenging the alignment, your team always comes out on top.Hofmann Geoliner 770XDSmall-Footprint

Hofmann Vin Reader

Vin Reader
Scans the vin and enters the vehicle into the aligner for a faster process. Rather than entering the information manually.

  • Next generation UI optimized for the high-volume user
  • Diagnostic alignment with “Compensate Warn Alert” intervention gets it right the first time
  • Unique camera beam design to fit through a standard doorway and protects cameras
  • Highly accurate and reliable XD camera technology
  • AC200 Clamps with XD Targets
  • Includes Vin Reader

Standard Accessories

Part Number Description
00055502000 Steering Wheel Holder
00000096000 Brake Pedal Depressor
EAK0268J05A Color Ink Jet Printer


Specifications geoliner™ 770XD EEWA752HV2
Tire Diameter 19" - 39" (48.3 cm - 99.1 cm)
Track Width 48" - 96" (122 cm - 244 cm)
Wheelbase 79" - 180" (201cm - 457cm)
Power Requirements 100-240V AC (must have earth ground) 1Ph 50/60Hz
UL201, C22.2, CE Approved
Shipping Weight 544 lbs (246.75 kg)
