Dannmar DB-70 - Automatic Wheel Balancer

$2,592.00

Please call us for customization options.

Dannmar’s DB-70 Wheel Balancer Keeps Everything Running Smoothly

Dannmar’s DB-70 wheel balancer handles wheels up to 28” diameter. The DB-70 is a highly accurate and dependable balancer that features Dannmar’s Digital Sensor Technology providing excellent reliability.

Most wheels can be quickly mounted to the balancer with the DB-70’s multi-size center cones. The full rubber perimeter no-mar “Quick-Nut” bell adapter carefully and tightly secures the tire and wheel.

An easy touch-pad panel displays tire and wheel assembly graphics. This helps simplify entry of wheel data and supports technicians through balancing procedures.

With the wheel setup on the balancer, the DB-70 automatically calculates the precise weight required to achieve an optimal balance. The brightly displayed LEDs indicate the exact amount and location of weight in just seven seconds. A full menu of time-saving features, including Dynamic and Static settings, allows you to balance most wheels with minimal effort and quick speed.

Dannmar’s DB-70 wheel balancer is ruggedly built and provides perfectly balanced wheels every time. With a proven dynamic and static wheel balancer to ensure smooth-spinning results, Dannmar provides a machine your technicians can use to keep the workflow moving and your busy customers happy.

Features

Six dynamic balancing modes and one static balancing mode
Manual wheel offset distance setting
Auto-start when hood is lowered
Wheel holding manual brake pedal
Truck cone/spacer ring adapter set
No-mar rear cone mount pressure cup
Quick-release and mount hub nut
LED rolling wheel weight displays
Easy-to-use controls

Specs

Motor	110-230 VAC, 50-60 Hz, 1-Ph
Cycle Time	7 seconds
Balancing Modes	6 Dynamic / 1 Static
Drive System	Serpentine Poly-V Belt
Wheel Braking	Lever Caliper Brake / Foot Pedal
Cones Included	4
Max. Tire Diameter	49” (1,247 mm)
Max. Tire Weight	150 lbs. (68 kg)
Wheel Diameter Capacity	10” - 28” (254 mm - 711 mm)
Wheel Width Capacity	1.5” - 20” (38 mm - 508 mm)
Balancing Increments	0.25 or 0.01 ounce
Balancing Speed	260 RPM
Accuracy	+- 1 Gram (.035 oz)
Noise	<70 dB
Shipping Weight	292 lbs. (132.4 kgs)
Shipping Dimensions	38" x 30" x 46" (965 mm x 762 mm x 1,168 mm)
