Tuxedo TP11KC-DX - 11,000 lb. Capacity Clear Floor Bi-symmetric 2-Post Lift

$5,350.00

Please call us for customization options.

Engineered and built to offer great features at an economical price, the TP11KC-DX features and designs will make this the most used lift in your garage. With versatile user-friendly Bi-Symmetric™ Configurable arms, 3 stage front arms, symmetric columns, single point lock release, low profile arms, rubber door guards and spin up pads with 2 " and 4" stackable truck adapters offers everything you'd expect and more!

3 Stage Front Arms and 2 Stage Rear Arms

180° Front Arm Rotation

Rubber Door Guards and Spin Up Pad Adapters

180° Front Arm Full Rotation

Optional TP11DX-SPNCA Set of Four Spin-Up Cradle Adapters

Auto Lift TP11DX-SPNCA spin-up cradle adapters

Features

11,000 lb lifting capacity
Asymmetric/Symmetric Arm Configuration
Direct Drive
3 Stage Front Arms
Symmetric Columns
Single Point Lock Release
Low Profile Arms
Rubber Doors Guards
Spin Up Pads

Specifications	TP11KC-DX
Capacity	11,000 lbs.
Overall Height	144"
Width Overall w/Power Unit	145-1/2"
Max Lift Height	71"
Min Pad Height	4"
Width Between Columns	116"
Drive thru Clearance	104"
Lifting speed	50 sec
Asymmetric / Symmetric	Both
Front Arm Reach - min/max	23" - 45"
Rear Arm Reach - min/max	41" - 45"
Clear Floor / Floor Plate	Clear Floor
Column Thickness	gauge # 7 or 3/16" (4.76 mm)
Power	220V - 20 AMP - 1 PH
Ship Weight	1,705 lbs.
