BendPak HD-973PX - Tri-Level Parking Lift

BendPak

Please call us for customization options.

The Longer, Higher Triple Decker

The tri-level HD-973PX is a four-post parking lift that maximizes your parking capacity without adding any additional real estate. Each HD-973PX houses up to three vehicles on strengthened parking platforms to give you the most space for your buck. With an additional 84” of overall height compared to the HD-973P parking lift, the HD-973PX supports some of the biggest vehicles around! This extra height, along with the additional 10” of runway length, gives you the perfect amount of space to fit longer and taller vehicles, while maintaining a height that will fit comfortably in most shops and garages. With the topmost platform’s weight capacity sitting at a hefty 7,000 lbs. and the lower deck handling up to 9,000 lbs., the HD-973PX is ideal for lifting even heavy-duty vehicles like full-size trucks and SUVs.

This rugged design is ready for installation indoors or outdoors, instantly tripling your parking and storing capability. The easy to use top-of-the-line design ensures that your vehicles are being lifted safely, and efficiently. Which saves you time, and worry. The safety features that come standard with any BendPak lift make sure your cars stay in the air until YOU move them, and intuitive design cycles through the cars at the push of a button. With the HD-973PX you’re getting a lift that can not only park your taller and longer vehicles, but fits comfortably and safely wherever you need it most.



Specifications
HD-973P
HD-973PX
Style
Multi-Level Parking Lift
Extended Multi-Level Parking Lift
Top Platform
7,000 lbs. (3,175 kg)
*Max Capacity / Front Axle
3,500 lbs. (1,588 kg)
*Max Capacity / Rear Axle
3,500 lbs. (1,588 kg)
A - Overall Width
112" (2,833 mm)
B - Overall Length
242" (6,141 mm)
252.25" (6,409 mm)
C - Height of Columns
161" (4,093 mm)
173" (4,398 mm)
D - Drive-thru Clearance
87" (2,201 mm)
E - Maximum Rise
139.5" (3,544 mm)
151.5" (3,849 mm)
F - Maximum Lifting Height
144" (3,667 mm)
156.5" (3,972 mm)
G - Distance Between Columns
100" (2,546 mm)
H - Runway Width
19" (482 mm)
I - Width Between Runways
44" (1,121 mm)
J - Runway Length
188.5" (4,786 mm)
199" (5,056 mm)
Min. Wheelbase @ rated Capacity 1
135" (3,429 mm)
140" (3,556 mm)
Min. Wheelbase @ 75% Capacity 1
115" (2,921 mm)
120" (3,084 mm)
Min. Wheelbase @ 50% Capacity 1
95" (2,413 mm)
100" (2,540 mm)
Min. Wheelbase @ 25% Capacity 1
75" (1,905 mm)
80" (2,032 mm)
Locking Positions
31
34
Locking Spacing
Every 4" (102 mm)
Lifting Time to Max. Rise
90 seconds
Motor
220 VAC / 60 Hz / 1 Ph
Bottom Platform
Lifting Capacity*
9,000 lbs. (4,082 kg)
*Max Capacity / Front Axle
4,500 lbs. (2,041 kg)
*Max Capacity / Rear Axle
4,500 lbs. (2,041 kg)
A - Overall Width
112" (2,833 mm)
B - Overall Length
242" (6,139 mm)
252.25" (6,409 mm)
C - Height of Columns
161" (4,093 mm)
245" (6,227 mm)
D - Drive-thru Clearance
90.25" (2,292 mm)
E - Maximum Rise
70" (1,783 mm)
82.25" (2,088 mm)
F - Maximum Lifting Height
75" (1,906 mm)
87.25" (2,211 mm)
G - Distance Between Columns
100" (2,546 mm)
H - Runway Width
19" (482 mm)
I - Width Between Runways
44" (1,121 mm)
J - Runway Length
176" (4,470 mm)
186.75" (4,744 mm)
Min. Wheelbase @ rated Capacity 1
125" (3,175 mm)
135" (3,429 mm)
Min. Wheelbase @ 75% Capacity 1
110" (2,794 mm)
115" (2,921 mm)
Min. Wheelbase @ 50% Capacity 1
90" (2,289 mm)
95" (2,413 mm)
Min. Wheelbase @ 25% Capacity 1
75" (1,905 mm)
75" (1,905 mm)
Locking Positions
13
16
Locking Spacing
Every 4" (102 mm)
Lifting Time to Max. Rise
50 seconds
Motor
220 VAC / 60 Hz / 1 Ph





Features

  • Extended length, high rise
  • Perfect for parking, storage and service
  • 7,000 lb. capacity upper deck
  • 9,000 lb. capacity lower deck
  • Superstructure features durable powder coat finish
  • Perfect for cars, trucks, and SUVs
  • Platforms feature full-length aluminum decking
  • Rugged welded-steel construction
  • Powerful hydraulic cylinders
  • Heavy-duty 3/8” lifting cable
  • Heavy-duty steel construction
  • Wide base-plate for maximum stability
  • Heavy-duty steel construction
  • Grease nipples are located on every sheave and sheave axle to make lubrication maintenance a breeze
  • Integrated hydraulic flow restrictor provides controlled descent in event of hose rupture
  • Reliable electric-hydraulic power system
  • Runways feature non-skid surface
  • Multi-position safety locks in each column
  • Automatic safety locks combined with redundant anti-fall devices
  • Adjustable lock ladders
  • Independent backup slack-cable safety latches
  • Push-button pneumatic safety release.
  • Padded trip bar with limit switch prevents lower vehicle from making contact with upper platform.
  • Simple controls
  • Optional drive-thru ramps available
  • Optional 4,500-lb. air-hydraulic rolling jacks available
